[Tutorial] How to create posters and put them in Oculus Home

LuluViBritanniaLuluViBritannia Posts: 453
Trinity
edited July 2018 in Oculus Rift S and Rift

Have you ever wished you were able to put your favourite pictures on your virtual walls? Well, this is possible with the Custom Objects feature! Well, it’s not a direct process, but I do manage to get posters in my Home, so I figured I would share this method, in case it would interest anyone.

I'm assuming you know the basics of Unity. If you don't... well of course, you can still try ^^. Otherwise, you can ask help from someone who does.


You’ll need the following software:

-        Oculus Home 2 (“no sh*t!”),

-        Unity, with a free Unity account + FBX Exporter (from Unity Asset Store)     OR Blender with the FBX add-on (find it in User Preferences).

-        Three.js editor (online tool, no need to download).

-        GLTF Converter (another online tool ; there are a few, but I suggest this one : https://blackthread.io/gltf-converter/).


Now, here is the process to put a poster in Home.

Short version :

0) Set-up : choose the picture you want, make sure you have Unity and the FBX Exporter asset, and prepare the online tools. Create a new project in Unity, import the FBX Exporter and the picture in this project.

1) In Unity, create a single plane and put the picture as its texture. Resize the plane to get the proper proportions (don't worry about the actual size).

2) With FBX Exporter, export this object as a FBX file. You now have a FBX object and a texture file.

3) Drag those two files in a GLTF converter. This will give you a single glb file.

4) Drag this glb file in three.js editor and reduce the size of the object. By default, the scale should be 0.1. Save the result as a new glb file.

5) Put the new glb file in the Import folder for Oculus Home, don't forget to rename it (by default it's "scene.glb" ...).

If the object is still too big, do step 4) again (reduce the size even more). There is a known problem where sometimes it doesn't change anything, I'm not sure where that comes from ^^'. Here is a nice tip : take one of your imported files as a size reference in three.js editor. Put the new file next to this one, and compare their size (you know the size of the reference object in Home, so by comparing a new object to it, you can have a pretty good idea of its size once imported).

With Blender, it is literally the same process : create plane, make that picture its texture, change the proportions, export is as .FBX file, convert it (with its texture) as .glb file, and so on ...



If you feel that you need a more detailed explanation, here is the long version (with Unity). It may seem long and hard but don't worry, it's actually not!

First of all, we need to create the “poster object”.
Choose any picture. I want this one in my Home:

 - Open a new project in Unity. Let's call it... nah, it doesn't matter anyway.
Put your picture in the project Asset folder. In the new scene, make a flat plane object. Finally, you have to import the asset. You should have something like this :

- Create a new material, and make that picture its texture. Then, just drop the material on the plane.

- Resize the plane to get the proper dimensions. Don’t worry about the actual size of the object, this will be dealt with later. Just make sure that the proportions of the picture are respected! (this is obviously not the case on the screenshot above...)

Okay, that was the first step: we just created our poster. Then, this object must be extracted from Unity.
Export this object as a .FBX file with FBX Exporter: right click on the object, and select “Export as FBX...”. If you don't find that option, restart Unity.
- In the assets folder of your Unity project, you should find that FBX object, along with its texture.

Now, you should have 2 files: the FBX object, and its texture. You have to convert that into a single glb file.
- Open the GLTF Converter.
Drop both these files in the proper place. The conversion won’t work if you don’t.
- The website should do the conversion by itself. If it worked, the "Export as GLB" button will be blue and selectable (don't worry if you don't see your object : that just means you see it from aside, and since it's flat, you can't see it from this point of view...). Click on that button, it will save the GLB file on your computer.


Okay, that was the first step: we just created our poster. Then, this object must be extracted from Unity.
Export this object as a .FBX file with FBX Exporter: right click on the object, and select “Export as FBX...”. If you don't find that option, restart Unity.
- In the assets folder of your Unity project, you should find that FBX object, along with its texture.

Now, you should have 2 files: the FBX object, and its texture. You have to convert that into a single glb file.
- Open the GLTF Converter.
Drop both these files in the proper place. The conversion won’t work if you don’t.
- The website should do the conversion by itself. If it worked, the "Export as GLB" button will be blue and selectable (don't worry if you don't see your object : that just means you see it from aside, and since it's flat, you can't see it from this point of view...). Click on that button, it will save the GLB file on your computer.


Now you have your poster object, and it's compatible with Oculus Home! But if you try to import it… you may encounter a "huge" problem. Indeed, your object will be way too big. Ten times its size, actually. So we need to rectify this.
- open the GLB file in three.js editor. The texture will be black, but don't worry! It will appear correctly in Home.
- resize the object (by default, use 0.1 as the size value) and save it as a new .GLB file (File\Export as GLB).
- Rename the new .GLB file and put it in the import folder.
- If 0.1 still gives you a huge object, try a smaller value. Sometimes I encounter a problem where changing the size this way doesn't actually change anything in Home ; I have no idea where this comes from ^^' I'd like to hear from someone who knows.

Then you will have a flat plane object, with a proper size, which we can call a poster ^^. I would put a picture of the final result... but I don't know how to make a screenshot of my Home xD (again, if anyone has a suggestion to do this, I'd love to hear them out...).



Hopefully this helped anyone! I was pretty proud of my small discovery, because posters are a good way to make a more personal room. Besides, 3D models are great but can take up a lot of resources. Pictures don't take anything so it's a framerate-friendly custom method :) .

Current VR results imo:
- Great small apps. Great ports of bigger games.
- Great VR-specific features. Not enough showcased!!!
- Too many actors in the industry, the market is totally broken.


My hopes for VR next gen:

- Better ratio between visual quality and power needs. No more godrays and less SDE.
- Full Body Tracking.


"If you don't mind, do you want me to take you there? Where dreams come true."

Comments

  • Calimero_OeufCalimero_Oeuf Posts: 53
    Hiro Protagonist
    edited July 2018
    Thanks
    Ma configuration Oculus Rift + 3 capteurs et câbles longueur 5 mètres :
    Cable USB 3.0 en 5 mètres x4
    Cable HDMI en 5 mètres x1
    Répétiteur HDMI x1
    Hub USB 3.0 pour 1 ou 2 capteurs x1
    Hub USB alimenté pour le casque  x1

  • LuluViBritanniaLuluViBritannia Posts: 453
    Trinity
    edited July 2018
    Hey there, I see you edited your post, does that mean you solved your problem? Because with my method, I also get trouble aligning my pictures on the wall. If anyone else gets this problem : first make sure your plane object is aligned on a plane of the Unity space (or Blender space). Then, in Home, you just have to tweak a little. Move the poster a bit (with your hand, not with the thumbstick), it is capricious but it will wind up aligning properly xD!

    Also, I'm editing the first post to say that we can use Blender as well. I had tried this one before Unity, but setting-up the texture was a bit of trouble... But it does work (I don't know what I was doing wrong, lol).
    Current VR results imo:
    - Great small apps. Great ports of bigger games.
    - Great VR-specific features. Not enough showcased!!!
    - Too many actors in the industry, the market is totally broken.


    My hopes for VR next gen:

    - Better ratio between visual quality and power needs. No more godrays and less SDE.
    - Full Body Tracking.


    "If you don't mind, do you want me to take you there? Where dreams come true."
  • Calimero_OeufCalimero_Oeuf Posts: 53
    Hiro Protagonist
    edited July 2018
    Yes I solved it with blender by making a cube with very small faces for the borders like a real drawing
    You need a small thickness to avoid problem when aligning on walls, that's why I created a cube.

    After some hours of tries with Blender (very big noob, I never use it before)
    I have no more problem now and alignement on walls is perfect without any tweaking.

    Ma configuration Oculus Rift + 3 capteurs et câbles longueur 5 mètres :
    Cable USB 3.0 en 5 mètres x4
    Cable HDMI en 5 mètres x1
    Répétiteur HDMI x1
    Hub USB 3.0 pour 1 ou 2 capteurs x1
    Hub USB alimenté pour le casque  x1

  • NoobfearNoobfear Posts: 1
    NerveGear
    Thank you for taking the time to make this guide, it was the final piece i was working on for my home i can now add everything and be happy.

    just small addition if you use blender the khronos group do a gltf exporter for it so you can skip a step of converting it

  • emperorvoidemperorvoid Posts: 1
    NerveGear
    For the love of dog can some of you wonderful people share these wonderful glb files?????????????????????
  • LZoltowskiLZoltowski Posts: 6,721 Volunteer Moderator
    Amazing work people!!!
    Core i7-7700k @ 4.9 Ghz | 32 GB DDR4 Corsair Vengeance @ 3000Mhz | 2x 1TB Samsung Evo | 2x 4GB WD Black
    ASUS MAXIMUS IX HERO | MSI AERO GTX 1080 OC @ 2000Mhz | Corsair Carbide Series 400C White (RGB FTW!)

    Be kind to one another :)
  • CalibosCalibos Posts: 92
    Hiro Protagonist
    For the love of dog can some of you wonderful people share these wonderful glb files?????????????????????
    Seconded!

    It'd be amazing if someone could build some frame models of different sizes and designs with the resolution specs listed that the rest of us can just add our own posters once we've cropped and/or scaled them. I'm not asking for much am I? :D
  • LZoltowskiLZoltowski Posts: 6,721 Volunteer Moderator
    Calibos said:
    For the love of dog can some of you wonderful people share these wonderful glb files?????????????????????
    Seconded!

    It'd be amazing if someone could build some frame models of different sizes and designs with the resolution specs listed that the rest of us can just add our own posters once we've cropped and/or scaled them. I'm not asking for much am I? :D

    Another easy way to make a 2D image for posting in your home is to use this site: https://glb-frame-maker.glitch.me/

    1. Choose frame
    2. Drag and drop a picture into the browser with the correct dimensions
    3. Download GLB
    4. Move to My Documents/Home/_Import
    5. Profit

    Suggested by @jessicazeta from the Medium crew

    Core i7-7700k @ 4.9 Ghz | 32 GB DDR4 Corsair Vengeance @ 3000Mhz | 2x 1TB Samsung Evo | 2x 4GB WD Black
    ASUS MAXIMUS IX HERO | MSI AERO GTX 1080 OC @ 2000Mhz | Corsair Carbide Series 400C White (RGB FTW!)

    Be kind to one another :)
  • Digikid1Digikid1 Posts: 1,839 Valuable Player
    Calibos said:
    For the love of dog can some of you wonderful people share these wonderful glb files?????????????????????
    Seconded!

    It'd be amazing if someone could build some frame models of different sizes and designs with the resolution specs listed that the rest of us can just add our own posters once we've cropped and/or scaled them. I'm not asking for much am I? :D

    Another easy way to make a 2D image for posting in your home is to use this site: https://glb-frame-maker.glitch.me/

    1. Choose frame
    2. Drag and drop a picture into the browser with the correct dimensions
    3. Download GLB
    4. Move to My Documents/Home/_Import
    5. Profit

    Suggested by @jessicazeta from the Medium crew

    Can you suggest what is good dimensions for home?
  • KlodsBrikKlodsBrik Posts: 1,116
    Wintermute
    Time to decorate all my walls with my favorite  porn actresses in every thinkable pose possible.
    Thx for the tutorial tips. :)
    Be good, die great !
  • LithiumIOLithiumIO Posts: 23
    Brain Burst
    Calibos said:
    For the love of dog can some of you wonderful people share these wonderful glb files?????????????????????
    Seconded!

    It'd be amazing if someone could build some frame models of different sizes and designs with the resolution specs listed that the rest of us can just add our own posters once we've cropped and/or scaled them. I'm not asking for much am I? :D
    Here is link to my Reddit thread and model depository - https://www.reddit.com/r/oculus/comments/9g2y2r/las_home_20_model_collection/

  • Digikid1Digikid1 Posts: 1,839 Valuable Player
    LithiumIO said:
    Calibos said:
    For the love of dog can some of you wonderful people share these wonderful glb files?????????????????????
    Seconded!

    It'd be amazing if someone could build some frame models of different sizes and designs with the resolution specs listed that the rest of us can just add our own posters once we've cropped and/or scaled them. I'm not asking for much am I? :D
    Here is link to my Reddit thread and model depository - https://www.reddit.com/r/oculus/comments/9g2y2r/las_home_20_model_collection/

    Awesome!  Thanks!  Can you also do some models of the Enterprises from Star Trek??
  • LithiumIOLithiumIO Posts: 23
    Brain Burst
    Digikid1 said:
    Awesome!  Thanks!  Can you also do some models of the Enterprises from Star Trek??
    If you can find one on SketchFab that's:
    1. Free and downloadable
    2. Isn't a bazillion polygons
    3. Can be sized to meet the 15Mb maximum file size of Oculus Home (refer to point 2)
    Post the link here and I'll see what I can do, or better yet comment on my Reddit thread as I have notifications turned on there. Try to keep the triangles count around 60-80k maximum as a general rule for any chance of being able to convert and use it.
  • Pavel419Pavel419 Posts: 12
    NerveGear
    edited December 2018
    How to add physics to such a model? The pictures themselves are easily made in a blender, but - they remain independent of gravity, for example. I want them to be thrown like a baseball, but I don’t know how to do it ...





  • IlMissile95IlMissile95 Posts: 10
    NerveGear
    Where do you get your supply from?
  • Digikid1Digikid1 Posts: 1,839 Valuable Player
    @LithiumIO I've made a post in the off topic section regarding this.....can you see if you can help me out?  Thanks.
  • HotWasabiPeasHotWasabiPeas Posts: 19 Oculus Start Member
    edited April 23
    There is an app in the Oculus Store for exporting photo objects for Oculus Home:


    It has frames of varying sizes and some frames that automatically fit your image file. Makes adding photos to your Home pretty easy and painless.
  • Digikid1Digikid1 Posts: 1,839 Valuable Player
    You posted a link to THIS EXACT THREAD.

    How exactly is that helpful?
